Expansion Anchors Manufacturers in India
- Home
- Anchor Fasteners
- Expansion Anchors
As a leading Expansion Anchors Manufacturers in India, we offer anchors engineered for precision and performance reliability. The Expansion Anchors produced by AFT provide a multitude of advantages. To begin with, the most significant advantage of Expansion Anchors is how much confidence they instilled in the contractor and builder community. Conversely, many believe that Expansion Anchors can reliably and effectively provide the high safety needed in tough conditions.
Expansion Anchors provide contractors with a reliable source to construct strong, durable buildings. All Expansion Anchors utilize an expander feature inside the drilled hole within the concrete or masonry that allows them to hold securely and maintain their grip. Expansion Anchors have been widely recognized as having high load capacities regardless of corrosion or other environmental factors, and they have the advantage of a simple installation procedure. Expansion Anchors are extensively used in the construction industry, industrial construction, and heavy-duty applications.
Expansion Anchors: Overview and Working Mechanism
AFT (Anchorite Fixing Technology) manufactures exceptionally high-quality Expansion Anchors that allow you to securely connect fixtures and structures to concrete or masonry using an industry-standard level of reliability. Once the Expansion Anchor is installed, it expands and forms a very secure mechanical interlock with the concrete or masonry base materials. Therefore, when building in India, AFT is very highly regarded as they manufacture and produce Expansion Anchors that provide immediate load carrying capacities and also allow the installation to take place quickly.
Expansion anchors are well-suited for both structural and non-structural applications and are resistant to pull-out forces, vibration, and shear loading. Contractors and engineers rely on AFT's superior quality anchors for long-term stability and precision in demanding construction environments.
Applications and Performance
- Used to secure components into concrete and masonry
- Provide instant load-bearing capacity after installation
- Expand to create a strong mechanical grip
- Suitable for both structural and non-structural uses
Expansion Anchors Suppliers & Dealers in India – Affordable & Reliable Solutions
As a reputed Expansion Anchors Suppliers in India, we ensure that your projects never face delays. With strong logistic support and ready availability, we provide a timely supply of anchors that are suitable for commercial construction, railings, pipelines, and machinery anchoring.
As a reliable Expansion Anchors Dealers in India, we have a large selection of quality anchors that are easy to install, durable, and affordable. We are able to provide immediate service by having inventory on-hand, and therefore, our customers can expect to receive all products quickly without sacrificing quality.
We dedicate ourselves to providing all customers with Expansion Anchors that perform from an initial installation to completion of any size project. With Expansion Anchors being among the most commonly used anchoring devices across the country, they are ideal for use in residential buildings and industrial facilities.
Key Features and Engineering of Expansion Anchors
AFT (Anchorite Fixing Technology) Expansion Anchors are engineered for exceptional strength, durability, and consistent performance. They deliver immediate load-bearing strength, saving time on-site for critical projects. Designed for cracked and non-cracked concrete, these anchors handle static and dynamic loads efficiently. Their engineering principles of controlled expansion, friction, and proper load distribution ensure that forces are evenly transferred, minimizing risk of loosening or failure. With AFT’s expertise, construction teams achieve maximum reliability, safety, and performance, making these Expansion Anchors a trusted choice for industrial and infrastructure projects.
Strength and Engineering Highlights
- High load capacity and long-lasting durability
- Immediate strength upon installation
- Effective in cracked and non-cracked concrete
- Engineered for controlled expansion and friction-based holding
Expansion Anchors Wholesalers in India– Bulk Supply Made Simple
When it comes to large quantities of Expansion Anchors, AFT is one of the leading Expansion Anchors Wholesalers in India due to the availability of quality products and a competitive price. Construction companies and industries typically purchase Expansion Anchors from AFT in bulk, at substantially lower prices than if purchased through retail distribution channels.
We cater to the needs of big infrastructure and industrial projects. With large stock availability and a commitment to quality, we ensure smooth supply for projects of every scale.
Application of Expansion Anchors
- Railings, balusters, and staircases
- Structural steel support
- Commercial & residential construction
- Heavy equipment platforms
- Electrical, HVAC, and pipeline supports
Expansion Anchors: Design, Installation, and Practical Applications
AFT (Anchorite Fixing Technology) designs Expansion Anchors with expansion sleeves, cones, and threaded bolts for precise and secure anchoring. Their careful design ensures controlled expansion without compromising concrete integrity. Proper installation includes accurate drilling, hole cleaning, correct embedment depth, and torque application.
When installed per AFT’s guidelines, these anchors provide long-term reliability. Our Anchor System has been specifically created for use in various types of project applications, including machine mounting, steel fabrication, railings, and support brackets; therefore, we can provide you with the technology to help your business grow!
Design and Installation Essentials
- Components include expansion sleeves and threaded elements
- Require accurate drilling, hole preparation, and cleaning
- Proper torque ensures secure and long-lasting anchoring
- Widely used for heavy-duty construction fixings
Why Choose Our Expansion Anchors?
- Trusted by contractors and industries nationwide
- Competitive pricing for retail and wholesale
- Easy installation and reliable grip
- Available in multiple sizes and specifications
- High Strength and corrosion resistance
Contact us today to get the best Expansion Anchors at competitive prices for your next project
• Lightweight steel support structures
• Staircase railings
• False ceiling support brackets
• Wall-mounted equipment frames
• Lighting fixtures and sign boards
| Code | Art No. | Bolt Dia (mm) | Anchor Length (mm) | Drill Hole Ø (mm) In Structures |
T Fix Max (mm) | Effective Embedded Depth (mm) | Min. Drill Hole Depth (mm) | Recommended Torque (Nm) | Recommended Load KN Uncracked Concrete C20/25 Tensile |
Recommended Load KN Uncracked Concrete C20/25 Shear |
Distance Between Anchors (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ASA-SR-06050 | 3327750 | 6 | 50 | 10 | 5 | 40 | 50 | 12 | 3.5 | 4.0 | 65 |
| ASA-SR-06060 | 3327751 | 6 | 60 | 10 | 10 | 40 | 50 | 12 | 3.5 | 4.0 | 65 |
| ASA-SR-06080 | 3327752 | 6 | 80 | 10 | 20 | 40 | 50 | 12 | 3.5 | 4.0 | 65 |
| ASA-SR-08060 | 3327753 | 8 | 60 | 12 | 5 | 50 | 60 | 35 | 4.5 | 5.0 | 80 |
| ASA-SR-08075 | 3327754 | 8 | 75 | 12 | 15 | 50 | 60 | 35 | 4.5 | 5.0 | 80 |
| ASA-SR-08100 | 3327755 | 8 | 100 | 12 | 20 | 50 | 60 | 35 | 4.5 | 5.0 | 80 |
| ASA-SR-10070 | 3327760 | 10 | 70 | 14 | 10 | 60 | 70 | 70 | 7.0 | 8.0 | 100 |
| ASA-SR-10080 | 3327761 | 10 | 80 | 14 | 25 | 65 | 70 | 70 | 7.0 | 8.0 | 100 |
| ASA-SR-10110 | 3327762 | 10 | 110 | 14 | 40 | 80 | 70 | 70 | 7.0 | 8.0 | 100 |
• Façade secondary framing and brackets
• Handrails and railing posts
• Cable trays and service brackets
• Pipe supports and hanger brackets
• HVAC light equipment supports
• Window frame & door frame fixings
| Code | Art No. | Bolt Dia (mm) | Anchor Length (mm) | Drill Hole Ø (mm) In Structures |
T Fix Max (mm) | Effective Embedded Depth (mm) | Min. Drill Hole Depth (mm) | Recommended Torque (Nm) | Recommended Load KN Uncracked Concrete C20/25 Tensile |
Recommended Load KN Uncracked Concrete C20/25 Shear |
Distance Between Anchors (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ASA-SR-06050 | 3327850 | 6 | 50 | 10 | 5 | 40 | 50 | 12 | 3.8 | 4.3 | 65 |
| ASA-SR-06060 | 3327851 | 6 | 60 | 10 | 10 | 40 | 50 | 12 | 3.8 | 4.3 | 65 |
| ASA-SR-06080 | 3327852 | 6 | 80 | 10 | 20 | 40 | 50 | 12 | 3.8 | 4.3 | 65 |
| ASA-SR-08060 | 3327853 | 8 | 60 | 12 | 5 | 50 | 60 | 35 | 4.8 | 5.3 | 80 |
| ASA-SR-08075 | 3327854 | 8 | 75 | 12 | 15 | 50 | 60 | 35 | 4.8 | 5.3 | 80 |
| ASA-SR-08100 | 3327855 | 8 | 100 | 12 | 20 | 50 | 60 | 35 | 4.8 | 5.3 | 80 |
| ASA-SR-10070 | 3327860 | 10 | 70 | 14 | 10 | 60 | 70 | 70 | 7.2 | 8.2 | 100 |
| ASA-SR-10080 | 3327861 | 10 | 80 | 14 | 25 | 65 | 70 | 70 | 7.2 | 8.2 | 100 |
| ASA-SR-10110 | 3327862 | 10 | 110 | 14 | 40 | 80 | 70 | 70 | 7.2 | 8.2 | 100 |
• Light fixtures and pendant supports
• Signage and display hangers
• Sensor mounts and camera brackets
• Temporary service installations
• Access panels and maintenance fixtures
| Code | Art No. | Φ Drill (mm) | Anchor Length (mm) | Thread Size (mm) | Drill Hole Depth (mm) | Screw In Depth Min (mm) | Screw In Depth Max (mm) | Max. Recommended Torque (Nm) | Recommended Load KN Uncracked Concrete C20/25 Tension |
Recommended Load KN Uncracked Concrete C20/25 Shear |
Box Packing Content (Pcs.) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A-SDI-082506 | 4175011 | 8 | 25 | 6 | 27 | 6 | 12 | 4.5 | 2.1 | 1.7 | 100 |
| A-SDI-103008 | 4175012 | 10 | 30 | 8 | 32 | 8 | 13 | 11 | 3.6 | 3.1 | 100 |
| A-SDI-123010 | 4175013 | 12 | 30 | 10 | 42 | 10 | 15 | 22 | 4.8 | 4.5 | 50 |
| A-SDI-124010 | 4175014 | 12 | 40 | 10 | 43 | 10 | 17 | 22 | 4.8 | 4.5 | 50 |
| A-SDI-165012 | 4175015 | 16 | 50 | 12 | 53 | 12 | 22 | 38 | 6.3 | 7.3 | 50 |
| A-SDI-206516 | 4175016 | 20 | 65 | 16 | 69 | 16 | 27 | 95 | 10.5 | 12.2 | 25 |
| A-SDI-258020 | 4175017 | 25 | 80 | 20 | 84 | 20 | 34 | 185 | 11.9 | 17.2 | 25 |
• Light fixtures and pendant supports
• Signage and display hangers
• Sensor mounts and camera brackets
• Temporary service installations
• Access panels and maintenance fixtures
| Code | Art No. | Φ Drill (mm) | Anchor Length (mm) | Thread Size (mm) | Drill Hole Depth (mm) | Screw In Depth Min (mm) | Screw In Depth Max (mm) | Max. Recommended Torque (Nm) | Recommended Load KN Uncracked Concrete C20/25 Tension |
Recommended Load KN Uncracked Concrete C20/25 Shear |
Box Packing Content (Pcs.) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A-SDI-C-082506 | 4175021 | 8 | 25 | 6 | 27 | 6 | 12 | 4.5 | 2.1 | 1.7 | 100 |
| A-SDI-C-103008 | 4175022 | 10 | 30 | 8 | 32 | 8 | 13 | 11 | 3.6 | 3.1 | 100 |
| A-SDI-C-104008 | 4175023 | 10 | 40 | 8 | 42 | 8 | 20 | 11 | 3.6 | 3.1 | 50 |
| A-SDI-C-123010 | 4175024 | 12 | 30 | 10 | 33 | 10 | 15 | 22 | 4.8 | 4.5 | 50 |
| A-SDI-C-124010 | 4175025 | 12 | 40 | 10 | 43 | 10 | 17 | 22 | 4.8 | 4.5 | 50 |
| A-SDI-C-165012 | 4175026 | 16 | 50 | 12 | 53 | 12 | 22 | 38 | 6.3 | 7.3 | 50 |
| A-SDI-C-206516 | 4175027 | 20 | 65 | 16 | 69 | 16 | 27 | 95 | 10.5 | 12.2 | 25 |
| A-SDI-C-258020 | 4175028 | 25 | 80 | 20 | 84 | 20 | 34 | 185 | 11.9 | 17.2 | 25 |
• Overhead service supports
• Suspended cable tray systems
• Fire sprinkler pipe hangers
• HVAC duct hangers
• False ceiling suspension rods
| Code | Art No. | Φ Drill (mm) | Anchor Length (mm) | Thread Size (mm) | Drill Hole Depth (mm) | Screw In Depth Min (mm) | Screw In Depth Max (mm) | Max. Recommended Torque (Nm) | Recommended Load KN Uncracked Concrete C20/25 Tension |
Recommended Load KN Uncracked Concrete C20/25 Shear |
Box Packing Content (Pcs.) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A-SDI-R-082506 | 4175031 | 8 | 25 | 6 | 27 | 6 | 12 | 4.5 | 2.5 | 2.0 | 100 |
| A-SDI-R-103008 | 4175032 | 10 | 30 | 8 | 32 | 8 | 13 | 11 | 3.8 | 3.5 | 100 |
| A-SDI-R-124010 | 4175033 | 12 | 40 | 10 | 43 | 10 | 17 | 22 | 5.0 | 4.7 | 50 |
| A-SDI-R-165012 | 4175034 | 16 | 50 | 12 | 53 | 12 | 22 | 38 | 6.5 | 7.5 | 50 |
| A-SDI-R-206516 | 4175035 | 20 | 65 | 16 | 69 | 16 | 27 | 95 | 10.8 | 12.5 | 25 |
| A-SDI-R-258020 | 4175036 | 25 | 80 | 20 | 84 | 20 | 34 | 185 | 12.2 | 17.5 | 25 |
• Overhead service supports
• Suspended cable tray systems
• Fire sprinkler pipe hangers
• HVAC duct hangers
• False ceiling suspension rods
| Code | Art No. | Φ Drill (mm) | Anchor Length (mm) | Thread Size (mm) | Drill Hole Depth (mm) | Screw In Depth Min (mm) | Screw In Depth Max (mm) | Max. Recommended Torque (Nm) | Recommended Load KN Uncracked Concrete C20/25 Tension |
Recommended Load KN Uncracked Concrete C20/25 Shear |
Box Packing Content (Pcs.) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A-SDI-SR-082506 | 4175041 | 8 | 25 | 6 | 27 | 6 | 12 | 4.5 | 2.7 | 2.3 | 100 |
| A-SDI-SR-103008 | 4175042 | 10 | 30 | 8 | 32 | 8 | 13 | 11 | 4.0 | 3.7 | 100 |
| A-SDI-SR-124010 | 4175043 | 12 | 40 | 10 | 43 | 10 | 17 | 22 | 5.1 | 4.9 | 50 |
| A-SDI-SR-165012 | 4175044 | 16 | 50 | 12 | 53 | 12 | 22 | 38 | 6.8 | 7.7 | 50 |
| A-SDI-SR-206516 | 4175045 | 20 | 65 | 16 | 69 | 16 | 27 | 95 | 11.0 | 12.7 | 25 |
| A-SDI-SR-258020 | 4175046 | 25 | 80 | 20 | 84 | 20 | 34 | 185 | 12.4 | 17.6 | 25 |
