AFT, recognized as a Through-bolt Anchor Manufacturers in India, offers durability and strength. A through-bolt anchor, or wedge anchor, expands inside a drilled hole to secure structural components. It is commonly used when you are confident the connection is static, whether you are fastening steel beams, façade systems, or mounting machinery. Each bolt is precisely manufactured in a variety of Through bolt anchor sizes for heavy or medium applications.
Anchors are manufactured for a practical application. Builders across the city appreciate our designs based on their durability, especially for solid concrete slabs. Contractors typically utilize our anchors for elements such as stairwells, railings, and curtain walling brackets. We offer stainless steel and hot-dipped galvanized options, so our through-bolt anchors perform and accommodate outdoor elements. Each component is tested adequately, whether you choose a standard option or a specifically designed one, thinking of Through bolt anchor design's focus.
Benefits and Applications
- Built to last – every anchor tested for performance in solid concrete bases.
- Through bolt size selections are used to guarantee a fit for either small or large loads.
- Workable in heavy duty application such as machinery, bridges, and structural beams.
- Painted and coated with corrosion-resistant paint.
- Used for secure installation of industrial doors, stairwells, and handrails.
Through-bolt Anchor Suppliers & Dealers in India – Steady Stock and Delivery
Being a Through-bolt Anchor Suppliers in India is more than just stocking bolts; it’s about providing materials that keep projects moving. Our through-bolts are packaged and delivered with care, ensuring contractors don’t face delays on-site. It often helps when you have the right Through Bolt Fastener in hand for a steel column or façade connection, and we make sure the right sizes and finishes are always ready.
AFT supports contractors with a wide selection of anchors that fit into diverse construction projects. From bridges to ventilation duct supports, our stock covers it all. Customers also look to us for competitive Through bolt fastener price, especially when working on high-volume projects. With timely supply and dependable quality, builders across India know they can count on us for both light-duty and heavy-duty requirements.
A Through-bolt Anchor Dealers in India offers the convenience of local access, helping contractors and buyers choose the right fastener on the spot. Our dealers carry a variety of through-bolts so you can compare finishes, weights, and sizes before committing. For instance, you might notice how practical it is when you can simply check the Through Bolt Breaker model alongside regular anchors, ensuring the right pick for the job.
Why Clients Trust Us
- Dealers maintain steady stocks of Through Bolt Breaker and standard anchors.
- Products ideal for everyday fixtures like staircases, awnings, and outdoor signs.
- Local presence ensures quick access to the right anchor sizes.
- Fair through bolt fastener price options suit both contractors and households.
- Supportive guidance to match anchor type with load and base material.
Through-bolt Anchor Wholesalers in India – Bulk Orders and Value
As a Through-bolt Anchor Wholesalers in India, AFT ensures distributors and large buyers get access to bulk orders at consistent quality and fair pricing. Our wholesale lots include wedge-style through-bolts in all Through Bolt sizes, from light-duty to heavy-duty structural applications. It often helps when you know every box in a shipment meets the same high standard.
When demand is high, bulk supply with a controlled through-bolt fastener price in India can make a real difference. You might notice how projects run more smoothly when bolts arrive on time and in uniform condition.
Key Advantages
- Competitive rates and consistent through bolt fastener price in bulk supply.
- Complete portfolio including ETA-approved Through Bolt Fastener ranges.
- Dependable packing ensures safe long-distance delivery to job sites.
- Stock of hot-dip galvanized and stainless anchors for outdoor use.
- Scalable supply for contractors, builders, and distributors across India.
Connect with our technical team to discuss through-bolt anchor requirements
• Canopy structures & sunshade frames
• Signage frames & advertising hoardings
• Industrial racking systems
• Safety barriers & crash barriers
• Seismic restraint connections for services
• Staircase stringer supports
• Retrofits and strengthening works
| CODE | ART NO. | ANCHOR DIA mm |
ANCHOR LENGTH mm |
DRILL HOLE DIA mm |
MINIMUM EMBED LENGTH (Hnom1) mm |
MAXIMUM EMBED LENGTH (Hnom2) mm |
MAXIMUM T.FIX Hnom1 / Hnom2 mm |
MINIMUM DRILL HOLE DEPTH Hnom1 / Hnom2 mm |
STD. THREAD LENGTH mm |
NUT DIA (SW) mm |
RECOMMENDED TORQUE Nm |
RECOMMENDED SAFE WORKING LOAD (Uncracked Concrete C20/25) Tensile / Shear (kN) |
SAFE DISTANCE BETWEEN ANCHORS mm |
SAFE EDGE DISTANCE mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ACS-R-08075 | 2017311 | 8 | 75 | 8 | 40 | 50 | 20 / 10 | 45 / 55 | 35 | 13 | 15 | 5.1 / 5.2 | 60 | 60 |
| ACS-R-10090 | 2017321 | 10 | 90 | 10 | 50 | 60 | 20 / 15 | 60 / 70 | 40 | 17 | 30 | 7.2 / 9.2 | 70 | 70 |
| ACS-R-10100 | 2017322 | 10 | 100 | 10 | 50 | 60 | 30 / 25 | 60 / 70 | 50 | 17 | 30 | 7.2 / 9.2 | 70 | 70 |
| ACS-R-10130 | 2017323 | 10 | 130 | 10 | 60 | 90 | 50 / 20 | 70 / 100 | 65 | 17 | 30 | 7.2 / 9.2 | 70 | 70 |
| ACS-R-12100 | 2017335 | 12 | 100 | 12 | 60 | 75 | 15 / 5 | 70 / 85 | 35 | 19 | 50 | 10.2 / 13.3 | 80 | 90 |
| ACS-R-12120 | 2017336 | 12 | 120 | 12 | 60 | 75 | 35 / 25 | 70 / 85 | 55 | 19 | 50 | 10.2 / 13.3 | 80 | 90 |
| ACS-R-12130 | 2017337 | 12 | 130 | 12 | 70 | 90 | 40 / 10 | 80 / 100 | 65 | 19 | 50 | 10.2 / 13.3 | 80 | 90 |
| ACS-R-12150 | 2017338 | 12 | 150 | 12 | 60 | 75 | 65 / 55 | 70 / 85 | 85 | 19 | 50 | 10.2 / 13.3 | 80 | 90 |
| ACS-R-16140 | 2017353 | 16 | 140 | 16 | 80 | 95 | 35 / 20 | 90 / 105 | 75 | 24 | 100 | 13.7 / 24.9 | 110 | 110 |
• Canopy structures & sunshade frames
• Signage frames & advertising hoardings
• Industrial racking systems
• Safety barriers & crash barriers
• Seismic restraint connections for services
• Staircase stringer supports
• Retrofits and strengthening works
| Code | Art No. | Anchor Dia mm |
Anchor Length mm |
Drill Hole Dia mm |
Min Embed Length Hnom1 (mm) |
Max Embed Length Hnom2 (mm) |
Max T.Fix Hnom1 / Hnom2 (mm) |
Min Drill Hole Depth Hnom1 / Hnom2 (mm) |
Std. Thread Length mm |
Nut Dia (SW) mm |
Recommended Torque Nm |
Safe Working Load (C20/25) Tensile / Shear (kN) |
Safe Distance Between Anchors mm |
Safe Edge Distance mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ACS-HS-06050 | 2017260 | 6 | 50 | 6 | 30 | 35 | 5 / - | 35 / 40 | 20 | 10 | 5 | 3.0 / 3.8 | 35 | 35 |
| ACS-HS-06065 | 2017261 | 6 | 65 | 6 | 35 | 40 | 10 / 5 | 40 / 45 | 30 | 10 | 5 | 3.8 / 3.9 | 35 | 35 |
| ACS-HS-06085 | 2017262 | 6 | 85 | 6 | 50 | 60 | 15 / 5 | 55 / 65 | 35 | 10 | 5 | 4.5 / 3.9 | 35 | 35 |
| ACS-HS-06100 | 2017263 | 6 | 100 | 6 | 55 | 65 | 25 / 15 | 60 / 70 | 45 | 10 | 5 | 4.5 / 3.9 | 35 | 35 |
| ACS-HS-08060 | 2017201 | 8 | 60 | 8 | 40 | - | 5 / - | 45 / - | 25 | 13 | 15 | 6.5 / 6.5 | 35 | 35 |
| ACS-HS-08075 | 2017202 | 8 | 75 | 8 | 40 | 50 | 15 / 5 | 45 / 55 | 40 | 13 | 15 | 6.5 / 6.5 | 35 | 35 |
| ACS-HS-08095 | 2017203 | 8 | 95 | 8 | 50 | 70 | 25 / 5 | 55 / 75 | 45 | 13 | 15 | 7.8 / 6.5 | 35 | 35 |
| ACS-HS-08115 | 2017204 | 8 | 115 | 8 | 50 | 80 | 45 / 15 | 55 / 85 | 55 | 13 | 15 | 7.8 / 6.5 | 35 | 35 |
| ACS-HS-10075 | 2017211 | 10 | 75 | 10 | 50 | 55 | 5 / - | 60 / 65 | 40 | 17 | 25 | 9.2 / 10.5 | 50 | 50 |
| ACS-HS-10095 | 2017212 | 10 | 95 | 10 | 50 | 60 | 25 / 15 | 60 / 70 | 45 | 17 | 25 | 9.2 / 10.5 | 50 | 50 |
| ACS-HS-10115 | 2017213 | 10 | 115 | 10 | 50 | 90 | 45 / 5 | 60 / 100 | 55 | 17 | 25 | 9.2 / 10.5 | 50 | 45 |
| ACS-HS-10130 | 2017215 | 10 | 130 | 10 | 60 | 90 | 50 / 20 | 70 / 100 | 65 | 17 | 25 | 10.3 / 10.8 | 50 | 40 |
| ACS-HS-10150 | 2017216 | 10 | 150 | 10 | 70 | 90 | 60 / 40 | 80 / 100 | 80 | 17 | 25 | 11.5 / 11.0 | 50 | 40 |
| ACS-HS-10170 | 2017217 | 10 | 170 | 10 | 70 | 90 | 80 / 60 | 80 / 100 | 95 | 17 | 25 | 11.5 / 11.0 | 50 | 40 |
| ACS-HS-12095 | 2017225 | 12 | 95 | 12 | 65 | 75 | 10 / - | 75 / 85 | 35 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-HS-12115 | 2017226 | 12 | 115 | 12 | 65 | 80 | 30 / 15 | 75 / 85 | 55 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-HS-12130 | 2017228 | 12 | 130 | 12 | 70 | 100 | 40 / 10 | 80 / 85 | 65 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-HS-12150 | 2017229 | 12 | 150 | 12 | 70 | 100 | 60 / 25 | 80 / 110 | 80 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-HS-12175 | 2017230 | 12 | 175 | 12 | 90 | 100 | 65 / 55 | 100 / 110 | 90 | 19 | 50 | 16.8 / 16.9 | 75 | 65 |
| ACS-HS-12205 | 2017231 | 12 | 205 | 12 | 90 | 100 | 90 / 80 | 100 / 110 | 95 | 19 | 50 | 16.8 / 16.9 | 75 | 65 |
| ACS-HS-12225 | 2017232 | 12 | 225 | 12 | 90 | 100 | 110 / 100 | 100 / 110 | 100 | 19 | 50 | 16.8 / 16.9 | 75 | 65 |
| ACS-HS-16105 | 2017241 | 16 | 105 | 16 | 75 | - | 10 / - | 85 / - | 50 | 24 | 80 | 17.5 / 29.7 | 90 | 80 |
| ACS-HS-16125 | 2017242 | 16 | 125 | 16 | 75 | 90 | 25 / 10 | 85 / 100 | 60 | 24 | 80 | 17.5 / 29.7 | 90 | 80 |
| ACS-HS-16145 | 2017243 | 16 | 145 | 16 | 75 | 100 | 45 / 25 | 85 / 110 | 75 | 24 | 80 | 17.5 / 29.7 | 90 | 80 |
| ACS-HS-16180 | 2017245 | 16 | 180 | 16 | 100 | 135 | 60 / 20 | 110 / 145 | 90 | 24 | 80 | 23.5 / 29.8 | 90 | 80 |
| ACS-HS-16235 | 2017246 | 16 | 235 | 16 | 100 | 135 | 100 / 75 | 110 / 145 | 95 | 24 | 80 | 23.5 / 29.8 | 90 | 80 |
| ACS-HS-20130 | 2017255 | 20 | 130 | 20 | 90 | 100 | 15 / 10 | 100 / 110 | 65 | 30 | 200 | 30.0 / 49.5 | 175 | 120 |
| ACS-HS-20170 | 2017256 | 20 | 170 | 20 | 90 | 130 | 60 / 20 | 100 / 140 | 80 | 30 | 200 | 30.0 / 49.5 | 175 | 120 |
NOTE :
*All load tolerances can be achieved in accordance with the specified dimensions mentioned above.
*Any modifications to the product portfolio can be implemented without prior notification to the stakeholders.
*Special lengths can be provided upon request, subject to a minimum order quantity requirement.
*KN= Kilonewton (1KN = 100Kgs.)
• Façade support brackets & façade sub-frame fixings
• Structural steel base plates
• Handrails, guardrails, balustrades
• Equipment foundations & machine base frames
• MEP supports: HVAC units, AHU frames, cable trays, pipe racks
| Code | Art No. | Anchor Dia mm |
Anchor Length mm |
Drill Hole Dia mm |
Min Embed Length Hnom1 (mm) |
Max Embed Length Hnom2 (mm) |
Max T.Fix Hnom1 / Hnom2 (mm) |
Min Drill Hole Depth Hnom1 / Hnom2 (mm) |
Std. Thread Length mm |
Nut Dia (SW) mm |
Recommended Torque Nm |
Safe Working Load (C20/25) Tensile / Shear (kN) |
Safe Distance Between Anchors mm |
Safe Edge Distance mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ACS-SR-06050 | 2017470 | 6 | 50 | 6 | 30 | 35 | 5 / - | 35 / 40 | 20 | 10 | 5 | 3.0 / 4.2 | 35 | 35 |
| ACS-SR-06065 | 2017471 | 6 | 65 | 6 | 35 | 40 | 10 / 5 | 40 / 45 | 30 | 10 | 5 | 3.8 / 4.2 | 35 | 35 |
| ACS-SR-06085 | 2017472 | 6 | 85 | 6 | 50 | 60 | 15 / 5 | 55 / 65 | 35 | 10 | 5 | 4.5 / 4.2 | 35 | 35 |
| ACS-SR-06100 | 2017473 | 6 | 100 | 6 | 55 | 65 | 25 / 15 | 60 / 70 | 45 | 10 | 5 | 4.5 / 4.2 | 35 | 35 |
| ACS-SR-08060 | 2017410 | 8 | 60 | 8 | 40 | - | 5 / - | 45 / - | 25 | 13 | 15 | 6.5 / 7.0 | 35 | 35 |
| ACS-SR-08075 | 2017411 | 8 | 75 | 8 | 40 | 50 | 15 / 5 | 45 / 55 | 40 | 13 | 15 | 6.5 / 7.0 | 35 | 35 |
| ACS-SR-08095 | 2017412 | 8 | 95 | 8 | 50 | 70 | 25 / 5 | 55 / 75 | 45 | 13 | 15 | 7.8 / 7.0 | 35 | 35 |
| ACS-SR-08115 | 2017413 | 8 | 115 | 8 | 50 | 80 | 45 / 15 | 55 / 85 | 55 | 13 | 15 | 7.8 / 7.0 | 35 | 35 |
| ACS-SR-10075 | 2017420 | 10 | 75 | 10 | 50 | 55 | 5 / - | 60 / 65 | 40 | 17 | 25 | 9.2 / 13.1 | 50 | 50 |
| ACS-SR-10095 | 2017421 | 10 | 95 | 10 | 50 | 60 | 25 / 15 | 60 / 70 | 45 | 17 | 25 | 9.2 / 13.1 | 50 | 50 |
| ACS-SR-10115 | 2017422 | 10 | 115 | 10 | 50 | 90 | 45 / 5 | 60 / 100 | 55 | 17 | 25 | 9.2 / 13.1 | 50 | 45 |
| ACS-SR-10130 | 2017423 | 10 | 130 | 10 | 60 | 90 | 50 / 20 | 70 / 100 | 65 | 17 | 25 | 10.3 / 13.1 | 50 | 40 |
| ACS-SR-10150 | 2017424 | 10 | 150 | 10 | 70 | 90 | 60 / 40 | 80 / 100 | 80 | 17 | 25 | 11.5 / 13.1 | 50 | 40 |
| ACS-SR-10170 | 2017425 | 10 | 170 | 10 | 70 | 90 | 80 / 60 | 80 / 100 | 95 | 17 | 25 | 11.5 / 13.1 | 50 | 40 |
| ACS-SR-12095 | 2017430 | 12 | 95 | 12 | 65 | 75 | 10 / - | 75 / 85 | 35 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-SR-12115 | 2017431 | 12 | 115 | 12 | 65 | 80 | 30 / 15 | 75 / 85 | 55 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-SR-12130 | 2017432 | 12 | 130 | 12 | 70 | 100 | 40 / 10 | 80 / 85 | 65 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-SR-12150 | 2017433 | 12 | 150 | 12 | 70 | 100 | 60 / 25 | 80 / 110 | 80 | 19 | 50 | 12.8 / 17.0 | 75 | 65 |
| ACS-SR-12175 | 2017434 | 12 | 175 | 12 | 90 | 100 | 65 / 55 | 100 / 110 | 90 | 19 | 50 | 16.8 / 16.9 | 75 | 65 |
| ACS-SR-12205 | 2017435 | 12 | 205 | 12 | 90 | 100 | 90 / 80 | 100 / 110 | 95 | 19 | 50 | 16.8 / 16.9 | 75 | 65 |
| ACS-SR-12225 | 2017435 | 12 | 225 | 12 | 90 | 100 | 110 / 100 | 100 / 110 | 100 | 19 | 50 | 16.8 / 16.9 | 75 | 65 |
| ACS-SR-16105 | 2017440 | 16 | 105 | 16 | 75 | - | 10 / - | 85 / - | 50 | 24 | 80 | 17.5 / 32.5 | 90 | 80 |
| ACS-SR-16125 | 2017441 | 16 | 125 | 16 | 75 | 90 | 25 / 10 | 85 / 100 | 60 | 24 | 80 | 17.5 / 32.5 | 90 | 80 |
| ACS-SR-16145 | 2017442 | 16 | 145 | 16 | 75 | 100 | 45 / 25 | 85 / 110 | 75 | 24 | 80 | 17.5 / 32.5 | 90 | 80 |
| ACS-SR-16180 | 2017443 | 16 | 180 | 16 | 100 | 135 | 60 / 20 | 110 / 145 | 90 | 24 | 80 | 23.5 / 32.5 |
• Façade support brackets & façade sub-frame fixings
• Structural steel base plates
• Handrails, guardrails, balustrades
• Equipment foundations & machine base frames
• MEP supports: HVAC units, AHU frames, cable trays, pipe racks
| Code | Art No. | Anchor Dia mm |
Anchor Length mm |
Drill Hole Dia mm |
Min Embed Length Hnom1 (mm) |
Max Embed Length Hnom2 (mm) |
Max T.Fix Hnom1 / Hnom2 (mm) |
Min Drill Hole Depth Hnom1 / Hnom2 (mm) |
Std. Thread Length mm |
Nut Dia (AF/SW) mm |
Recommended Torque Nm |
Safe Working Load (Uncracked C20/25) Tensile / Shear (kN) |
Safe Working Load (Cracked C20/25) Tensile / Shear (kN) |
Safe Distance Between Anchors mm |
Safe Edge Distance mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AHS-AS-08075 | 2017511 | 8 | 75 | 8 | 50 | 55 | 15 / 10 | 55 / 60 | 40 | 13 | 20 | 7.0 / 8.0 | 4.0 / 8.0 | 35 | 40 |
| AHS-AS-08095 | 2017512 | 8 | 95 | 8 | 50 | 55 | 30 / 25 | 55 / 60 | 45 | 13 | 20 | 7.0 / 8.0 | 4.0 / 8.0 | 35 | 40 |
| AHS-AS-08115 | 2017513 | 8 | 115 | 8 | 55 | 100 | 50 / 5 | 60 / 105 | 60 | 13 | 20 | 7.0 / 8.0 | 4.0 / 8.0 | 35 | 40 |
| AHS-AS-10090 | 2017520 | 10 | 90 | 10 | 50 | 70 | 25 / 10 | 60 / 80 | 45 | 17 | 45 | 11.0 / 13.5 | 7.5 / 13.5 | 50 | 45 |
| AHS-AS-10100 | 2017521 | 10 | 100 | 10 | 50 | 70 | 35 / 20 | 60 / 80 | 50 | 17 | 45 | 11.0 / 13.5 | 7.5 / 13.5 | 50 | 45 |
| AHS-AS-10120 | 2017522 | 10 | 120 | 10 | 50 | 70 | 50 / 30 | 60 / 80 | 60 | 17 | 45 | 11.0 / 13.5 | 7.5 / 13.5 | 50 | 45 |
| AHS-AS-10130 | 2017523 | 10 | 130 | 10 | 50 | 100 | 60 / 10 | 60 / 110 | 70 | 17 | 45 | 11.0 / 13.5 | 7.5 / 13.5 | 50 | 45 |
| AHS-AS-10150 | 2017524 | 10 | 150 | 10 | 50 | 100 | 80 / 30 | 60 / 110 | 80 | 17 | 45 | 11.0 / 13.5 | 7.5 / 13.5 | 50 | 45 |
| AHS-AS-10200 | 2017525 | 10 | 200 | 10 | 50 | 100 | 130 / 80 | 60 / 110 | 100 | 17 | 45 | 11.0 / 13.5 | 7.5 / 13.5 | 50 | 45 |
| AHS-AS-12100 | 2017535 | 12 | 100 | 12 | 60 | 75 | 20 / 5 | 70 / 85 | 50 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12120 | 2017536 | 12 | 120 | 12 | 60 | 80 | 35 / 20 | 70 / 90 | 60 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12130 | 2017537 | 12 | 130 | 12 | 60 | 80 | 45 / 25 | 70 / 90 | 70 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12150 | 2017538 | 12 | 150 | 12 | 60 | 80 | 65 / 30 | 70 / 90 | 80 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12170 | 2017539 | 12 | 170 | 12 | 60 | 135 | 90 / 15 | 70 / 145 | 90 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12230 | 2017540 | 12 | 230 | 12 | 60 | 135 | 150 / 75 | 70 / 145 | 95 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12260 | 2017541 | 12 | 260 | 12 | 60 | 135 | 180 / 100 | 70 / 145 | 100 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-12300 | 2017542 | 12 | 300 | 12 | 60 | 135 | 220 / 140 | 70 / 145 | 100 | 19 | 60 | 13.5 / 19.5 | 9.5 / 19.5 | 60 | 55 |
| AHS-AS-16150 | 2017550 | 16 | 150 | 16 | 80 | 100 | 50 / 30 | 90 / 110 | 80 | 24 | 110 | 18.5 / 33.0 | 13.0 / 33.0 | 80 | 75 |
| AHS-AS-16170 | 2017551 | 16 | 170 | 16 | 80 | 100 | 70 / 50 | 90 / 110 | 90 | 24 | 110 | 18.5 / 33.0 | 13.0 / 33.0 | 80 | 75 |
| AHS-AS-16220 | 2017552 | 16 | 220 | 16 | 80 | 175 | 120 / 25 | 90 / 185 | 95 | 24 | 110 | 18.5 / 33.0 | 13.0 / 33.0 | 80 | 75 |
| AHS-AS-16260 | 2017553 | 16 | 260 | 16 | 80 | 175 | 150 / 90 | 90 / 185 | 100 | 24 | 110 | 18.5 / 32.0 | 13.0 / 33.0 | 80 | 75 |
| AHS-AS-16300 | 2017554 | 16 | 300 | 16 | 80 | 175 | 200 / 80 | 90 / 185 | 100 | 24 | 110 | 18.5 / 32.0 | 13.0 / 33.0 | 80 | 75 |
| AHS-AS-20170 | 2017560 | 20 | 170 | 20 | 120 | 120 | 30 / 30 | 130 / 130 | 85 | 30 | 240 | 32.0 / 53.5 | 17.0 / 48.5 | 120 | 110 |
| AHS-AS-20200 | 2017561 | 20 | 200 | 20 | 120 | 120 | 60 / 60 | 130 / 130 | 90 | 30 | 240 | 32.0 / 53.5 | 17.0 / 48.5 | 120 | 110 |
| AHS-AS-20260 | 2017562 | 20 | 260 | 20 | 120 | 200 | 120 / 40 | 130 / 130 | 100 | 30 | 240 | 32.0 / 53.5 | 17.0 / 48.5 | 120 | 110 |
| AHS-AS-24200 | 2017570 | 24 | 200 | 24 | 150 | 150 | 30 / 30 | 160 / 160 | 90 | 36 | 300 | 33.5 / 55.0 | 19.0 / 50.0 | 180 | 170 |
| AHS-AS-24230 | 2017571 | 24 | 230 | 24 | 150 | 170 | 60 / 40 | 160 / 180 | 95 | 36 | 300 | 33.5 / 55.0 | 19.0 / 50.0 | 180 | 170 |
